Introduction of Functional Features and the advantages OF small tube laser cutting machine
Equipment name: HSST-9A automatic high-speed Small laser pipe cutting machine
It is a laser pipe cutting machine customized for the small pipe and mini metal pipe industry. At present, it is mainly used in furniture, kitchen utensils, fitness equipment, children’s cars and other industries that need to use small metal pipes.
1. Laser cutting machine with simple operation and fast cutting speed.
2.The mechanical structure adopts an integrated bed design, welded with steel plates, and the equipment runs smoothly.
3.The model adopts fully automatic numerical control system and is equipped with computer operation interface.
4.This model adopts AC servo motor drive system, and the machine tool movement adopts imported linear guide rails to ensure high-speed, stable, high-precision, high-reliability long-term operation of the equipment.
Technical Parameters of small tube laser cutting machine
| Item | Parameters |
| Laser wavelength | 1070-1080nm |
| max pipe length | ≤6200mm |
| Repeatability of machine tool positioning accuracy | ±0.03mm |
| positioning accuracy | ±0.05mm |
| tailing length | ≤40mm |
| Power supply rated voltage | 3phrase 380v 50Hz |
| Machine out dimension | 9.5m X 2m X 2m |
Equipment processing capacity OF small tube laser cutting machine
| Item | Round tube | Square pipe |
| Standard size | Φ12mm-Φ80mm | 12*12-60*60mm |
| Mark | Very small tubeΦ10mm | Very small tube10*10mm |
Equipment cutting capacity OF small tube laser cutting machine
| Power source 1500W | |
| Carbon steel | 0.5-5mm |
| Stainless steel | 0.5-3mm |
| Aluminum | 0.5-2mm |
| brass | 0.5-2mm |
